See the full list of free documents by manufacturer all on one page. Select the car or van model and see the available manuals in PDF. Exterior light check Press the exterior light check switch (1) on the ignition key or remote control for 2 seconds. Spoiler settings To minimise fuel consumption, adjust the roof spoiler as indicated. Air suspension height settings Adjust the front and/or rear axle of the vehicle and/or the axles of the trailer to. DAF XF95 EBS braking fault. The customer complained of an EBS braking fault which occurred intermittently. When the fault occurred then the EBS light would illuminate on the display and the EBS function would revert to conventional braking. This fault had been a problem for some time. Nevada National Security Site. Device Assembly Facility (DAF) Construction began on the Device Assembly Facility (DAF) in the mid-1980s to support underground nuclear testing. The DAF was designed and built to consolidate all nuclear explosive assembly functions, to provide safe structures for high explosive and nuclear explosive assembly.
©
1-3
VIC fault codes
VIC
DAVIE XD diagnostics manual
4
13404-24
Short circuit to earth or excessive load on pin E04
of the ECU
-
Prime mover right flasher lights: not flashing
at the rear, flashing with too high a
frequency at the front
13404-5
Interruption or insufficient load on pin E04 of the
ECU
-
Prime mover right flasher lights are not
working
13405-24
Short circuit to earth or excessive load on pin A07
of the ECU
-
Drawn vehicle left flasher lights are not
working
13406-24
Short circuit to earth or excessive load on pin A08
of the ECU
-
Drawn vehicle right flasher lights are not
working
21301-3
Short circuit to supply on pin D16 of the ECU
-
Air pressure gauge, circuit 1, gives no
reading
21301-20
Interruption or short circuit to earth on pin D16 of
the ECU
-
Air pressure gauge, circuit 1, gives no
reading
21301-23
Voltage out of range; voltage between 0 and 1 V
on pin D16 of the ECU
-
Air pressure gauge, circuit 1, gives no
reading
21301-25
Voltage out of range; voltage between 4 and 5 V
on pin D16 of the ECU
-
Air pressure gauge, circuit 1, gives no
reading
21302-3
Daf Warning Lights Manual Download
Short circuit to supply on pin D11 of the ECU
-
Air pressure gauge, circuit 1, gives no
reading
21302-20
Interruption or short circuit to earth on pin D11 of
the ECU
-
Air pressure gauge, circuit 2, gives no
reading
21302-23
Voltage out of range; voltage between 0 and 1 V
on pin D11 of the ECU
-
Air pressure gauge, circuit 2, gives no
reading
21302-25
Voltage out of range; voltage between 4 and 5 V
on pin D11 of the ECU
-
Air pressure gauge, circuit 2, gives no
reading
21303-3
Short circuit to supply on pin D31 of the ECU
-
Air pressure gauges, circuits 1 and 2, give
no reading
21303-4
Short circuit to earth on pin D31 of the ECU
-
Flashing instrument lighting on DIP-4, no
possibility to read fault codes
21901-3
Short circuit to supply on pin B24 of the ECU
-
The traction control can be activated
independently of speed; normally the
traction control can no longer be activated
above 30 km/h
22001-21
Interruption on pin C05 of the ECU or interruption
in the voltage supply
-
Rear fog light relay is no longer
automatically deactivated when the lighting
is switched off
22002-3
Short circuit to supply on pin C40 of the ECU
-
Rear fog lights remain lit, irrespective of the
position of the switch
22002-20
Interruption or short circuit to earth on pin C40 of
the ECU
Warning Lights Mini Lightbars
-
Rear fog lights are not working
22601-21
Interruption on pin C08 of the ECU
-
No glow indication on DIP-4
Daf Warning Lights Manual Diagram
22901-22
Interruption or short circuit to supply on pin D15 of
the ECU
-
Yellow warning 'Coolant level low' is
activated
22901-23
Voltage signal is outside of tolerance field
-
Information on the main display does not
correspond with the actual coolant level; a
warning may be displayed
23801-4
Short circuit to earth on pin D04 of the ECU
-
Instrument lighting can no longer be dimmed
Fault code
Fault code description with possible cause
Symptom
| Vehicle details: | DAF XF95 |
| Symptom: | ABS fault, EBS fault |
| Author: | DAF & Pico |
The customer complained of an EBS braking fault which occurred intermittently. When the fault occurred then the EBS light would illuminate on the display and the EBS function would revert to conventional braking. This fault had been a problem for some time.
When the vehicle's electronic systems were interrogated the same faults were always apparent:
- EBS ECU under voltage fault code for the power supply to the ECU.
- Engine ECU over voltage fault code for the power supply to the ECU.
The driver also reported that the radio fuse would blow regularly and that the interior lights would dim momentarily.
The vehicle was subjected to a variety of electrical tests to try and determine if the wiring harness or ECUs were damaged. It was noted that the starter motor and alternator both functioned correctly and that the power supply to the components measured at 24V. Further detailed inspections of harnesses on the chassis and in the cab provided no lead as to the under-voltage and over-voltage situations occurring simultaneously on both ECUs.
Diagnosis
The DAF UK technical department were requested to assist. During their diagnosis of the vehicle, the vehicle's ECUs were monitored with the PicoScope oscilloscope for power fluctuations. During a road test the oscilloscope picked up anomalies in voltage supply which occurred for just a few milliseconds.
The trace below identifies a momentary voltage and current spike detected at the power supply to cab and to the Engine ECU for a period of 60 ms, but essentially it was noted that this occurred when the vehicle started to pull away from a rough road lay-by
- Blue – Current draw on main power to cab
- Orange – Current at the battery bridge
- Green – UPEC wake up voltage
- Red – UPEC battery feed
This unusual fluctuation led the diagnosing engineer to investigate further, particularly the vibration on the power supply waveform. The driver was asked to drive in a variety of load related situations and the technical engineer monitored the scope for anomalies. As the vehicle slowed down in top gear full throttle was applied causing the engine to labour creating symmetrical spikes on the current draw into the cab as shown below.
The x axis is divided by 20 ms divisions and the spikes are repeated at a regular frequency of circa 5 ms.
- Blue – Current draw on main power to cab
- Orange – Current at the battery bridge
- Green – UPEC wake up voltage
- Red – UPEC battery feed
At this point no fault had yet occurred but it could clearly be seen that a symmetrical resonance was creating a power supply issue.
Further testing found that when the exhaust brake was applied with the service brake, then the following spikes were created. On this occasion the voltage to the engine ECU spiked in time to the current spike of the main cab supply.
The voltage to the engine ECU exceeded the set range of the oscilloscope and was in excess of 50 volts. The current draw into the cab momentarily exceeded 50 amps.
- Blue – Current draw on main power to cab
- Orange – Current at the battery bridge
- Green – Engine ECU wake up voltage
- Red – Engine ECU battery feed
Whilst the vehicle was being inspected and this set of waveforms being captured in the workshop, it was noticed that at idle the interior lights of the cab started to pulsate slightly.
The below trace shown is for a period of one second only and it clearly shows the voltages to engine ECU and EBS ECU spiking in time with the interior lights pulsating..
- Blue – Current draw on main power to cab
- Orange – EBS voltage
- Green – Current draw through relay G126
- Red – Engine ECU battery feed
The fault
It was determined that a main power supply anomaly feeding the cab was the cause. It was known that earlier investigations had ruled out the starter motor, alternator and the main harness to the cab. Therefore the battery cables were manipulated whilst the oscilloscope continued to record the voltage spikes in time with the dimming interior lights. When the battery bridge cable was disturbed the waveform settled to a linear output as would normally be expected.
Close inspection of the battery bridge cable found a cracked solder joint between the cable and the battery clamp.
Conclusion
The oscilloscope allowed for multiple channel monitoring and gave graphical depiction of the unfolding problem that could be detected and analysed. The clues from the symmetrical waveforms and the timing of the natural resonance from the engine led to the investigation concentrating on a poor main power supply connection. Systematic manipulation of each of the main battery cables whilst observing the PicoScope traces allowed for immediate response of the waveform once the problem area was disturbed.
Repair
Replacement of the battery bridge cable restored a guaranteed linear voltage supply to the vehicle.
Daf Warning Lights Manually
Very cool. I used a similar method to find a intermittent charging system problem on a 30 ft. Gillig Transit Bus.
By ’ battery bridge cable ’ i presume this is what links the batteries to 24V the system ? I used to call it a link lead.
Now if this is the case then surely it must have had a starting/charging issue somewhere along the way too ??
What was the reason for DAF UK Technical to be called in ?
It just seems typical to me of a dealer (if i presume correctly that you are an agent for DAF ?)that if the fault isn’t found in a click of a finger via GFF not to spend any more time & pass it on or revert to ‘swoptronics’.
Anyway it’s nice to see an HGV case study & would like to see a few more, when i was HGV based & had a scope been mentioned i would thought it was what was on the top of a rifle (DMM in them days) 😊
Interesting challenge which would surely have gone on for longer without the use of the PicoScope.
